Outdoor Curved Soft LED Screen Display P4.81 SMD RGB LED Display for House Supermarket Using

IKE Visual Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Outdoor Curved Soft LED Screen Display P4.81 SMD RGB LED Display for House Supermarket Using from wholesalers

    Buy cheap Outdoor Curved Soft LED Screen Display P4.81 SMD RGB LED Display for House Supermarket Using from wholesalers
    • Buy cheap Outdoor Curved Soft LED Screen Display P4.81 SMD RGB LED Display for House Supermarket Using from wholesalers
    • Buy cheap Outdoor Curved Soft LED Screen Display P4.81 SMD RGB LED Display for House Supermarket Using from wholesalers
    • Buy cheap Outdoor Curved Soft LED Screen Display P4.81 SMD RGB LED Display for House Supermarket Using from wholesalers

    Outdoor Curved Soft LED Screen Display P4.81 SMD RGB LED Display for House Supermarket Using

    Ask Lasest Price
    Brand Name : IKE Visual
    Model Number : Wind O-4
    Certification : CE,RoHS,FCC
    Price : negotiate
    Payment Terms : T/T, Western Union
    Supply Ability : 500PCS/Month
    Delivery Time : 12 days
    • Product Details
    • Company Profile

    Outdoor Curved Soft LED Screen Display P4.81 SMD RGB LED Display for House Supermarket Using

    Outdoor Curved Soft LED Screen Display P4.81 SMD RGB LED Display for House Supermarket Using

    Overview
    Wind O-4
    Quick Details
    Application:
    Outdoor,semi-outdoor
    Color:
    Full color
    Waterproof
    IP65
    Pixel Pitch:
    P4.6875
    LED Type:
    1921SMD
    LED Chio
    3 in1 SMD
    Place of Origin:
    Guangdong, China
    Model Number:
    Wind O-4
    Power Consumption
    (Max./Avg.)
    830W /㎡ / 277 W/㎡
    Panel size:
    W1200mm*H600mm
    Use:
    Advertising publish, retail store, shopping mall,stage
    Product name:
    Flexible LED display
    Brightness:
    4500 nits
    Media Available:
    Datasheet, Photo, EDA/CAD Models
    Max. Curve:
    Min.Diameter 77cm Concave Or Convex
    Scan mode:
    1/16S
    Pixel density:
    45512 px/smq
    Control system:
    Novastar
    Weight:
    17.9kg/sqm
    Refresh Rate:
    1920Hz
    Customized:
    Accept
    Product Description
    • Stable quality
    • CE,FCC,RoHS
    • Waterproof available
    • Energy Saving
    • Customized Shape
    • 2-3 years warranty

    Our Service

    1. Replied in 24hrs
    2. OEM & ODM
    3. Provide lifelong warranty
    4. After you buy this product, we will provide you with attentive after-sales service. Our engineers will carefully guide the installation and usage for you. That will includes connection of the controller and the light, and also the control software.


    Wind Series flexible LED display offers outstanding performance with its real flexibility.


    The unique design contributes to the horizontal and vertical deformed bending installation, making it possible to achieve “S”shaped, round, concave, convex and curved screen.


    The special soft PCB board design allows Wind series being ever-changing,no matter if you would want concave shape in a concert now,and cylinder LED display in a supermall tomorrow,even would provide a touring show for a stage 2 days later,it will be easily done by Wind Series .

    Outdoor Curved Soft LED Screen Display P4.81 SMD RGB LED Display for House Supermarket Using

    We have CE ROHS FCC.
    Model No
    Wind-3
    Wind-4/Wind O-4
    Wind-6/Wind O-6
    Wind-9/Wind O-9
    Wind-12/Wind O-12
    Pixel Pitch
    P3.125mm
    P4.6875 mm
    P6.25 mm
    P9.375 mm
    P12.5mm
    Density
    102400 Pixels/㎡
    45512 Pixels/㎡
    25600 Pixels/㎡
    11378 Pixels/㎡
    6400 Pixels/㎡
    Brightness
    1200 Nits
    1200 Nits/5000 Nits
    1200 Nits/5000 Nits
    1200 Nits/5000 Nits
    1200 Nits/5000 Nits
    IP Degree
    IP43
    IP43/IP65
    IP43/IP65
    IP43/IP65
    IP43/IP65
    Panel Size
    800mm*400mm
    1200mm*600mm
    1200mm*600mm
    1200mm*600mm
    1600mm*800mm
    Customized Available
    Module Resolution
    256 x 128
    256 x 128
    192 x 96
    192 x 96
    192 x 96
    Weight
    17.5kg/㎡
    17.9kg/㎡
    17.5kg/㎡
    17.5kg/㎡
    17.2kg/㎡
    Scan Mode
    1/16 Scan
    1/16 Scan
    1/8 Scan
    1/8 Scan│1/4 Scan
    1/8 Scan│1/2 Scan
    Max. Power Consumption
    800 W /㎡
    Indoor: 700 W /㎡
    Indoor: 700 W /㎡
    Indoor: 300 W /㎡
    Indoor: 200 W /㎡
    Outdoor:830 W/㎡
    Outdoor:830 W/㎡
    Outdoor:600 W/㎡
    Outdoor:600 W/㎡
    Avg. Power Consumption
    267 W/㎡
    Indoor: 230W /㎡
    Indoor: 230 W /㎡
    Indoor: 100 W /㎡
    Indoor: 80 W /㎡
    Outdoor:280W/㎡
    Outdoor:280 W/㎡
    Outdoor:200 W/㎡
    Outdoor:200 W/㎡
    Viewing Angle
    120 degree
    Working Voltage
    DC 5V
    Input Voltage
    AC 100-240V
    Thickness
    7.0cm (With Electronic Box) 1.3cm(Without Electronic Box)

    • Good after sold service

    Outdoor Curved Soft LED Screen Display P4.81 SMD RGB LED Display for House Supermarket Using


    FAQ:

    Q1. Can I have a sample order for led display?
    A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

    Q2. What about the lead time?
    A:Sample needs 3 days, mass production time needs about 14 days

    Q3. Do you have any MOQ limit for led light order?
    A: Low MOQ, 1pc for sample checking is available

    Q4. How do you ship the goods and how long does it take to arrive?
    A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

    Q5. How to proceed an order for led display?
    A: Firstly let us know your requirements or application.
    Secondly We quote according to your requirements or our suggestions.
    Thirdly customer confirms the samples and places deposit for formal order.
    Fourthly We arrange the production.

    Q6: Do you offer guarantee for the products?
    A: Yes, we offer 2 years warranty to our products.

    Q7: How to deal with the faulty?
    A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
    Secondly,spare parts of led module are prepared.
