Full Color P3 Transparent Advertising Screen IP43 Indoor Shop Window LED Display

Ask Lasest Price
Brand Name :	IKE Visual
Model Number :	Shine 3
Certification :	CE,RoHS,FCC
Price :	Negotiate
Payment Terms :	T/T, Western Union
Supply Ability :	500PCS/Month
Delivery Time :	21days

Add to Cart

Product Details
Company Profile

Full Color P3 Transparent Advertising Screen IP43 Indoor Shop Window LED Display

P3 Indoor Full Color Transparent LED Display Screen Shop Window Advertising Display

Overview

Quick Details

Pixel Pitch:: X: P3.90625mm ; Y: P7.8125m

Color:: Full color

Panel Size:: 500*1000mm

Applications:: Stage,trade show,retail shop,indoor outdoor

Place of Origin:: Guangdong, China

Model Number:: Shine 3

Brand Name:: IKE Visual

Product name:: Transparent LED display

Brightness:: 1200nits

LED chip:: 3 in 1 smd

Life span:: 100000 Hrs

Scan mode:: 1/8S

Pixel density:: 32768 px/smq

Control system:: Novastar

Weight:: 17.9kg/sqm

Type:: led number display

Low power consumption transparency 70% see-through glass wall transparent LED display

•Aluminum profile, ultra-tin and light weight, 14kgs per sqm only.

•high transparency over 70%.

•Great Heat Dissipation can help to reduce failure and maintenance cost, extend lifespan.
•Quick positioning and installation, only need to connect power and signal cable.

•24/7 reliability, 100,000hrs life span at least.

Full Color P3 Transparent Advertising Screen IP43 Indoor Shop Window LED Display

We have CE ROHS FCC.

Specification
Brightness1500 Nits/4500 Nits1500 Nits/6000 Nits1500 Nits/6000 Nits1500 Nits/6000 Nits
Density32768 Pixels/㎡18432 Pixels/㎡12288 Pixels/㎡9216 Pixels/㎡
Transparency50%65%65%75%
Refresh Rate1,920Hz1,920Hz1,920Hz1,920Hz
Scan Mode1/8 Scan1/4 Scan1/4 Scan1/3 Scan
Panel SizeW1000mm*H500mmW1000mm*H500mmW1000mm*H500mmW1000mm*H500mm
Customized Available
Weight6.5 kg/per panel6.5 kg/per panel6.5kg/per panel6.5kg/per panel
Viewing Angle120.120.120.120.
IP DegreeIP 40/IP65IP 40/IP65IP 40/IP65IP 40/IP65
Working VoltageDC 5VDC 5VDC 5VDC 5V
Input VoltageAC 100-240VAC 100-240VAC 100-240VAC 100-240V
Indoor Power Consumption800W /㎡
/ 330W/㎡600W /㎡
/ 200W/㎡600W /㎡
/ 200W/㎡600W /㎡
/ 200W/㎡
Outdoor Power Consumption (Max./Avg.)600W /㎡
/ 200W/㎡800W /㎡
/ 330W/㎡800W /㎡
/ 330W/㎡800W /㎡
/330W/㎡
Working Temperature
-40~50℃-40~50℃-40~50℃-40~50℃
Good after sold service
Payment term: T/T , usually 30~50% down payment before
production,balance to be paid before delivery

Delivery time:Production lead time less 20 sqm is about 8-12
working days, more than 50 sqm. is about 15 working days

Free sample or not: Sample is available,but need to pay the
material cost and freight cost

Shipping port: Guangzhou/Shenzhen, Mainland China

MOQ: 2 sqm for led screen,and10pcs for led module

Guarantee:Two years quality guarantee,after two years,we will ask
for material cost only,customer pay freight cost

Product Tags:

P3 Transparent Advertising Screen

FCC Transparent Advertising Screen

IP43 Shop Window LED Display

Full Color P3 Transparent Advertising Screen IP43 Indoor Shop Window LED Display

Inquiry Cart 0

Send your message to this supplier


*From:	Your email address is incorrect!
*To:	IKE Visual Co., Ltd.
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Explore more Access Control & Accessories products from this supplier

Find Similar Products By Category:

Electronic Components & Supplies

Hot Searches:

IKE Visual Co., Ltd.

Full Color P3 Transparent Advertising Screen IP43 Indoor Shop Window LED Display

Full Color P3 Transparent Advertising Screen IP43 Indoor Shop Window LED Display

Full Color P3 Transparent Advertising Screen IP43 Indoor Shop Window LED Display

P3 Transparent Advertising Screen

FCC Transparent Advertising Screen

IP43 Shop Window LED Display

Full Color P3 Transparent Advertising Screen IP43 Indoor Shop Window LED Display

IKE Visual Co.Ltd.,situated in Shishan Science and Technology Park, Foshan, is a high-tech enterprise featuring the R&D and manufacture of LED displays.

We have our own factory covering an area of 10 thousand ㎡,while boasting an experienced research team adept at self-developing such LED products as customized LED screens, flexible LED video walls and transparent LED displays.

Specification
Brightness	1500 Nits/4500 Nits	1500 Nits/6000 Nits	1500 Nits/6000 Nits	1500 Nits/6000 Nits
Density	32768 Pixels/㎡	18432 Pixels/㎡	12288 Pixels/㎡	9216 Pixels/㎡
Transparency	50%	65%	65%	75%
Refresh Rate	1,920Hz	1,920Hz	1,920Hz	1,920Hz
Scan Mode	1/8 Scan	1/4 Scan	1/4 Scan	1/3 Scan
Panel Size	W1000mm*H500mm	W1000mm*H500mm	W1000mm*H500mm	W1000mm*H500mm
Panel Size	Customized Available
Weight	6.5 kg/per panel	6.5 kg/per panel	6.5kg/per panel	6.5kg/per panel
Viewing Angle	120.	120.	120.	120.
IP Degree	IP 40/IP65	IP 40/IP65	IP 40/IP65	IP 40/IP65
Working Voltage	DC 5V	DC 5V	DC 5V	DC 5V
Input Voltage	AC 100-240V	AC 100-240V	AC 100-240V	AC 100-240V
Indoor Power Consumption	800W /㎡ / 330W/㎡	600W /㎡ / 200W/㎡	600W /㎡ / 200W/㎡	600W /㎡ / 200W/㎡
Outdoor Power Consumption (Max./Avg.)	600W /㎡ / 200W/㎡	800W /㎡ / 330W/㎡	800W /㎡ / 330W/㎡	800W /㎡ /330W/㎡
Working Temperature	-40~50℃	-40~50℃	-40~50℃	-40~50℃
